China Plastic PVC

Basic Info.

Customized	Customized
Condition	New
After-sales Service	Engineer Team
Model	Sjsz65/132,80/156,92/188
Pipe Diameter	16-63mm,63-250mm,200-400mm
Machinery Test Rep	Provided
Power(W)	75kw
Voltage	380V or Customized
Haulling off Machine	Four Clrawer Type
Screw L/D Ratio	22:1
Video Outgoing-Inspection	Provided
After Warranty Service	Video Technical Support, Online Support, Spare PAR
Screw Material	Bimetalic
Screw Diameter (mm	51
Output (Kg/H)	250 - 350 Kg/H
Transport Package	Standred Sea Packing
Specification	25m*1m*4m
Trademark	TONGSAN
Origin	Shandong China
Production Capacity	3sets/ Month

Product Description

1.OUR PRODUCTS:
pvc making machine for extrusion PVC pipes
we have different models of PVC pipe making machine for making different PVC pipe diameter, below is our PVC pipe plant cost for your reference:

Model	Diameter	Approximately price	Production capacity	Main extruder power
51/105	16-50mm	30000-35000 USD	80-120kg/h	22kw
65/132	50-160mm	40000-46000 USD	150-240kg/h	37kw
80/156	160-315mm	65000-72000 USD	300-350kg/h	75kw
92/188	315-500mm	190000-200000 USD	400-500kg/h	110kw

Machine line:

No.	Equipment list for PVC pipe manufacturing plant	Quantity
1	Mixing machine	1 set
2	Auto feeder	2 sets
3	Conical double screw extruder	1 set
4	Die head and sizing mold	customized
5	1st cooling tank	1 set
6	2nd cooling tank	1 set
7	haul off device	1 set
8	auto cutting machine	1 set
9	Laser printer or ink jet printer	1 set
10	PVC pipe stacker	1 set
11	PVC pipe joint belling machine	1 set
12	Crushing machine	1 set
13	PVC powder milling machine	1 set
14	Air compressor	1 set
15	water chiller	1 set

Description of PVC window and door profile extrusion machine,WPC solid door frame making machine

1, plastic pvc profiles extrusion line is specializing in producing PVC plastic profiles including doors and windows profiles, decorative plates, tiny foaming profiles and decorative plates.2, pvc profile machine uses PVC powder as material to produce various sorts of the mentioned plastic profiles as profiles for doors and windows, decorative profiles, etc.3, By Absorbing advanced technology from abroad, our company developed the large plastic profile extrusion line, which is equipped with conical double-screw extruder, and it possesses the advantages of high degree automation, stable performance, high output and efficiency, etc.4, If change certain screw and mould, the pvc profile machine can directly extrude foaming profiles, and the effect is much better than that of single-screw.5, pvc profile extrusion line is optimumly designed by referring to the latest overseas technology, it bears the features of even plasticization, low cutting rate, high output, and long lifespan, etc. And it composes conical double-screw extruder, vacuum sizing platform, tractor, cutting and film coating machine and material stirring bracket,etc.6, The pvc profile machine is run by alternating current frequency controller or direct current controllable silicon. The temperature controlling instrument is introduced from abroad. In addition, the vacuum pump and traction engine of the auxiliary machines are quality products which can be maintained easily7, To match with different moulds, the shape-fixing platform of 4m, 6m, 8m or 11m, etc. can be chosen accordingly. The main machine with parallel double-screw is especially suitable for high-speed extrusion of various kinds of profiles.

Model	SJSZ-51	SJSZ-65A	SJSZ-80	SJSZ-92
Total Power(kw)	25	64	115	168
Max profile with (mm)	200mm	400mm	900mm	1500
Profile products	electricity truck, house deractive line, small profiles	window and door profile, wall panel, ceiling panel	door panel, furniture panel	door panel, furniture panel
